Applications:
Model MB433 double rollers thrice polishing machine is suitable for surface polishing of woven fabrics of natural and synthetic fibers, knitted fabrics and tufted fabrics. Mainly for polishing flannel, blankets and woolen fabrics,
The fabric surface is fluffy and soft after polishing, pile straight and shiny, comparable to natural fabrics.
Main technical data:
Item
|
Data
|
Nominal width (mm)
|
2000
|
2500
|
Diameter of polishing roller (mm)
|
370
|
415
|
Rotation rate of polishing roller (m/min)
|
300-900r/min(Φ370)
/300-800r/min(Φ415)
(Variable)
|
Direction of rotation
|
Forward/Reverse
|
Max. polishing temperature (°C)
|
250°C
|
Speed of fabric (m/min)
|
10-40
|
Heating power (Kw)
|
50.4/57.6
|
Motor power (not include exhauster) (kw)
|
33.5Kw/41.5Kw
|
Overall dimensions
|
L(mm)
|
5100
|
W(mm)
|
4530
|
5030
|
H(mm)
|
2625
|
|
